Emuge - 3/8" Diam, 7/16" LOC, 3 Flute Solid Carbide Roughing & Finishing End Mill - CrN Finish, 2-3/4" OAL, 3/8" Shank Diam, Cylindrical Shank, 40° Helix, Long Length
Item #: 47933932
Brand: Emuge
Model #: 2889RZ.0375
Exact Tooling IR#: 04
Features and Benefits
Solid carbide provides better rigidity than high speed steel. It is extremely heat resistant and used for high-speed applications on cast iron, nonferrous materials, plastic and other tough-to-machine materials.
Chromium Nitride (CrN) is a coating similar to TiN, but has higher heat resistance. It is commonly used on aluminum, brass, copper, nickel alloys and other non-ferrous metals.
Non-Center Cutting applications have peripheral teeth allowing for the user to side (radial) cut or contour an exterior surface. Used in applications where plunge cutting is not necessary.
| Product Specifications | |
|---|---|
| Mill Diameter (Inch) | 3/8 |
| End Type | Square |
| Chamfer Length (Decimal Inch) | 0.0080 |
| Number of Flutes | 3 |
| Material | Solid Carbide |
| Finish/Coating | CrN |
| Length of Cut (Inch) | 7/16 |
| Shank Diameter (Inch) | 3/8 |
| Overall Length (Inch) | 2-3/4 |
| Centercutting | Non-Center Cutting |
| Extended Reach | ExtendedReach |
| Shank Type | Cylindrical |
| Helix Angle | 40 |
| Reach Length (Inch) | 1-1/8 |
| Neck Diameter (Decimal Inch) | 0.3540 |
| Single or Double End | Single |
| Length Type | Long |
| Cutting Direction | Right Hand |
| Flute Direction | Right Hand |
| Mill Diameter Tolerance (Decimal Inch) | -0.0016 |
| Series/List | 2889RZ |
