Iscar - TCMT731 F3P Grade IC8150 Carbide Turning Insert - TiCN/Al2O3/TiN Finish, 60° Triangle, 2.38mm Thick, 0.4mm Corner Radius
Item #: 46677811
Brand: Iscar
Model #: 5566879
Exact Tooling IR#: 04
Features and Benefits
Solid carbide is extremely heat-resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
| Product Specifications | |
|---|---|
| Insert Style | TCMT |
| Insert Size | 731 |
| Material | Carbide |
| Length (mm) | 9.60 |
| Length (Decimal Inch) | 0.3780 |
| Thickness (Decimal Inch) | 0.0940 |
| Thickness (mm) | 2.38 |
| Corner Radius (mm) | 0.40 |
| Corner Radius (Decimal Inch) | 0.0160 |
| Manufacturer's Grade | IC8150 |
| Coating | TiCN/Al2O3/TiN |
| Chip Breaker | F3P |
| Hole Diameter (mm) | 2.50 |
| Hole Diameter (Decimal Inch) | 0.0980 |
| ISO Number | TCMT 731-F3P |
| Rake | Positive |
| Relief Angle | 7 |
| Coating Process | MTCVD |
| Manufacturers Catalog Number | 5566879 |
| Primary Workpiece Material | K; M; P |
| Secondary Workpiece Material | None |
| Included Angle | 60 |
| Insert Hand | Right Hand |
| Maximum Depth of Cut (mm) | 1.70 |
| Maximum Depth of Cut (Decimal Inch) | 0.0670 |
| Multi Use Application | Turning |
| Shape | Triangle |
