SKF - Radial Ball Bearings; Type: Deep Groove ; Style: Double Seal ; Bore Diameter (mm): 80.00 ; Outside Diameter (mm): 170.00 ; Outside Diameter (Decimal Inch): 6.6900 ; Width (Decimal Inch): 1.5400
Item #: 45668506
Brand: SKF
Model #: 6316 2RSJEM
Product Specifications
Radial Ball Bearings; Type: Deep Groove ; Style: Double Seal ; Bore Diameter (mm): 80.00 ; Outside Diameter (mm): 170.00 ; Outside Diameter (Decimal Inch): 6.6900 ; Width (Decimal Inch): 1.5400
| Type | Deep Groove |
| Style | Double Seal |
| Bore Diameter (mm) | 80.00 |
| Outside Diameter (mm) | 170.00 |
| Outside Diameter (Decimal Inch) | 6.6900 |
| Width (Decimal Inch) | 1.5400 |
| Width (mm) | 39.00 |
| Flange Type | Without Flange |
| Number of Rows | 1 |
| Bore Type | Round |
| Housing Material | Steel |
| Snap Ring Included | Without Snap Ring |
| Static Load Capacity (Lb.) | 86500 |
| Dynamic Load Capacity (Lb.) | 124000 |
| ABEC Scale | ABEC-3 |
| Maximum RPM | 2600 |
