Iscar - XNUW 1305, 90° Lead Angle SXCI Internal Right Hand Indexable Profiling Toolholder - 25mm Shank Width, 170mm Long, Through Coolant
Item #: 45387909
Brand: Iscar
Model #: 2801406
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Internal or External | Internal |
| Hand of Holder | Right Hand |
| Rake | Neutral |
| Insert Compatibility | XNUW 1305 |
| Toolholder Style | SXCI |
| Series | V-Lock |
| Through Coolant | Yes |
| Shank Width/Diameter (mm) | 25.00 |
| Overall Length (mm) | 170.00 |
| Insert Holding Method | Screw |
| Rake Angle | 0 |
| Lead Angle | 90 |
| Minimum Hole Diameter (mm) | 30.50 |
| Center to Cutting Edge (mm) | 17.00 |
| Head Length (mm) | 30.00 |
| Maximum Hole Depth (mm) | 4.00 |
| Insert Inscribed Circle (mm) | 12.70 |
| Complete Insert Compatibility | XNUW 1305-05 |
