Iscar - SVXC, Right Hand Cut, 112° Lead Angle, 25mm Shank Height x 25mm Shank Width, Neutral Rake Indexable Turning Toolholder - 150mm OAL, Series Isoturn
Item #: 45382413
Brand: Iscar
Model #: 3601093
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Hand of Holder | Right Hand |
| Toolholder Style | SVXC |
| Rake | Neutral |
| Series | Isoturn |
| Lead Angle | 112 |
| Shank Width (mm) | 25.00 |
| Shank Height (mm) | 25.00 |
| Overall Length (mm) | 150.00 |
| Multi-Use Tool | No |
| Insert Holding Method | Screw |
| Back of Bar to Cutting Edge (mm) | 32.00 |
| Head Length (mm) | 30.00 |
| Insert Inscribed Circle (Decimal Inch) | 0.3750 |
