Iscar - GRIP, HGN Insert, 65mm Head Length, 3mm Min Groove Width, Modular Grooving Cutting Unit Head - Left Hand Cut, System Size C4, Series CAMFIX, Heli-Grip
Item #: 45378320
Brand: Iscar
Model #: 2500667
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| System Size | C4 |
| Series Name | CAMFIX; Heli-Grip |
| Cutting Direction | Left Hand |
| Modular Head Style | Cutting Head |
| Insert Style | GRIP; HGN |
| Head Length/Projection (mm) | 65.00 |
| Head Length/Projection (Decimal Inch) | 2.5590 |
| Through Coolant | NonThrough Coolant |
| Center to Cutting Edge (mm) | 20.00 |
| Center to Cutting Edge (Decimal Inch) | 0.7874 |
| Maximum Groove Width (mm) | 3.18 |
| Maximum Groove Width (Decimal Inch) | 0.1250 |
| Complete Insert Compatibility | GRIP 3002Y; GRIP 3003Y; GRIP 3015Y; GRIP 318-040Y; GRIP 318-159Y |
| Minimum Groove Width (mm) | 3.00 |
| Minimum Groove Width (Decimal Inch) | 0.1180 |
