Schunk - HSK63A Taper Shank 16mm Hole End Mill Holder/Adapter - 63/64" Nose Diam, 95mm Projection, Through Coolant
Item #: 44460046
Brand: Schunk
Model #: 203355
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Shank Type | Taper Shank |
| Taper Size | HSK63A |
| Hole Diameter (mm) | 16.00 |
| Nose Diameter (mm) | 25.00 |
| Nose Diameter (Inch) | 63/64 |
| Projection (mm) | 95.00 |
| Through Coolant | Yes |
| Clamping Depth (mm) | 48.00 |
| Clamping Depth (Decimal Inch) | 1.8898 |
| Balanced to (RPM) | 25000 |
| TIR (Decimal Inch) | 0.0001 |
| TIR (mm) | 0.003 |
