Kennametal - Insert Style CC.., 40mm Head Length, Left Hand Cut, Internal Modular Threading Cutting Unit Head - System Size KM40TS, 27mm Center to Cutting Edge, Series S-Clamping
Item #: 42681585
Brand: Kennametal
Model #: 3959952
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| System Size | KM40TS |
| Series Name | S-Clamping |
| Thread Type | Internal |
| Cutting Direction | Left Hand |
| Center to Cutting Edge (mm) | 27.00 |
| Center to Cutting Edge (Decimal Inch) | 1.0630 |
| Head Length/Projection (mm) | 40.00 |
| Head Length/Projection (Decimal Inch) | 1.5748 |
| Insert Style | CC.. |
| Insert Holding Method | Screw |
| Minimum Hole Diameter (mm) | 50.00 |
| Minimum Hole Diameter (Decimal Inch) | 1.9685 |
| Maximum Hole Depth (mm) | 40.00 |
| Maximum Hole Depth (Decimal Inch) | 1.5748 |
