Walter - JSCL2C, Left Hand Cut, 95° Lead Angle, 12mm Shank Height x 12mm Shank Width, Positive Rake Indexable Turning Toolholder - 85mm OAL, CC..09T3.. FK6 Insert Compatibility, Series J
Item #: 39863030
Brand: Walter
Model #: 6733971
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Hand of Holder | Left Hand |
| Toolholder Style | JSCL2C |
| Rake | Positive |
| Series | J |
| Lead Angle | 95 |
| Shank Width (mm) | 12.00 |
| Shank Height (mm) | 12.00 |
| Overall Length (mm) | 85.00 |
| Insert Compatibility | CC..09T3.. |
| Multi-Use Application | Facing; Turning |
| Insert Holding Method | Screw |
| Head Length (mm) | 16.00 |
| ISO Number | CCMT060204-FK6 WKK10S |
| Shape | Rhombic 80 |
| Thickness (Decimal Inch) | 0.0940 |
| Series | CCMT-FK6 |
| Maximum Depth of Cut (mm) | 6.45 |
| Maximum Depth of Cut (Decimal Inch) | 0.2540 |
| Manufacturer's Grade | WKK10S |
| Length (mm) | 6.45 |
| Length (Decimal Inch) | 0.2540 |
| Insert Style | CCMT |
| Inscribed Circle (mm) | 6.35 |
| Inscribed Circle (Decimal Inch) | 0.2500 |
| Hole Diameter (mm) | 2.80 |
| Hole Diameter (Decimal Inch) | 0.1100 |
| Cutting Direction | Neutral |
| Coating Process | CVD |
| Corner Radius (mm) | 0.4 |
| Coating | TiCN+Al2O3+(TiCN) |
| Corner Radius (Decimal Inch) | 0.0160 |
| Chip Breaker | FK6 |
| Proprietary Coating Designation | WKK10S |
| Included Angle | 80 |
| Relief Angle | 7 |
| Thickness (mm) | 2.38 |
| Insert Hand | Neutral |
| Insert Length (Decimal Inch) | 0.2540 |
| Cutting Width (mm) | 6.45 |
| OverallLength (mm) | 6.45 |
| Overall Length (Decimal Inch) | 0.2540 |
| Insert Length (mm) | 6.4480 |
