Kennametal - External Thread, 16mm Max Cut of Depth, 3mm Min Groove Width, 125mm OAL, Left Hand Indexable Grooving Cutoff Toolholder - 20mm Shank Height x 20mm Shank Width, EG0300M03P02 Insert Style, EVSC Toolholder Style, Series Beyond Evolution
Item #: 37965068
Brand: Kennametal
Model #: 6179937
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Internal or External | External |
| Hand of Holder | Left Hand |
| Maximum Depth of Cut (mm) | 16.00 |
| Minimum Groove Width (mm) | 3.00 |
| Maximum Groove Width (mm) | 3.00 |
| Overall Length (mm) | 125.00 |
| Series | Beyond Evolution |
| Toolholder Style | EVSC |
| Insert Compatibility | EG0300M03P02 |
| Shank Height (mm) | 20.00 |
| Shank Width/Diameter (mm) | 20.00 |
| Through Coolant | Through Coolant |
| Insert Holding Method | Clamp |
| Head Height (mm) | 24.75 |
| Head Length (mm) | 27.50 |
| Shank Length (mm) | 97.50 |
