Boston Gear - 16 Pitch, 2-1/2" Pitch Diam, 40 Tooth Spur Gear - 1/2" Face Width, 1/2" Bore Diam, 1.69" Hub Diam, 14.5° Pressure Angle, Steel
Item #: 36682128
Brand: Boston Gear
Model #: NB40A
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Spur Gear |
| Number of Teeth | 40 |
| Hub Diameter (Decimal Inch) | 1.6900 |
| Pitch Diameter (Decimal Inch) | 2.5000 |
| Bore Diameter (Decimal Inch) | 0.5000 |
| Material | Steel |
| Face Width (Decimal Inch) | 0.5000 |
| Pressure Angle | 14.5 |
| PSC Code | 3020 |
