Sandvik Coromant - CCMT3809 XH Grade 4325 Carbide Turning Insert - TiCN/AI2O3/TiN Finish, 80° Diamond, 1-1/2" Inscr Circle, 3/8" Thick, 1/8" Corner Radius
Item #: 35009505
Brand: Sandvik Coromant
Model #: 6532156
Exact Tooling IR#: 04
Features and Benefits
Solid carbide is extremely heat-resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
| Product Specifications | |
|---|---|
| Insert Style | CCMT |
| Insert Size | 3809 |
| Material | Carbide |
| Inscribed Circle (mm) | 38.10 |
| Inscribed Circle (Decimal Inch) | 1.5000 |
| Inscribed Circle (Inch) | 1-1/2 |
| Thickness (Inch) | 3/8 |
| Thickness (Decimal Inch) | 0.3750 |
| Thickness (mm) | 9.53 |
| Corner Radius (Inch) | 1/8 |
| Corner Radius (mm) | 3.175 |
| Corner Radius (Decimal Inch) | 0.1250 |
| Manufacturer's Grade | 4325 |
| Coating | TiCN/AI2O3/TiN |
| Chip Breaker | XH |
| Hole Diameter (mm) | 9.00 |
| Hole Diameter (Decimal Inch) | 0.3543 |
| ISO Number | CCMT 38 09 32-XH 4325 |
| Relief Angle | 7 |
| Coating Process | CVD |
| Included Angle | 80 |
| Cutting Direction | Neutral |
| Insert Hand | Neutral |
| Series | CoroTurn 107 |
| Maximum Depth of Cut (mm) | 38.00 |
| Insert Holding Method | Screw |
| Cutting Edge Style | Rounded |
| Shape | Diamond |
