Indexable Copy Face Mills; Maximum Depth Of Cut: 6.00 mm; Compatible Insert Size Code: RN.. 1204; Arbor Hole Diameter (mm): 22.00; Maximum Ramping Angle: 0 ™; Overall Height (mm): 40.00 mm; Series: A262-12; Number of Cutter Inserts: 5; Cutter Style: A262
Item #: 33951575
Brand: Ceratizit
Model #: 5078905005
Product Specifications
| Maximum Depth Of Cut | 6.00 mm |
| Compatible Insert Size Code | RN.. 1204 |
| Arbor Hole Diameter (mm) | 22.00 |
| Maximum Ramping Angle | 0 ? |
| Overall Height (mm) | 40.00 mm |
| Series | A262-12 |
| Number of Cutter Inserts | 5 |
| Cutter Style | A262 |
| Maximum Rpm | 14100.000 |
| Tool Application | Face Milling |
| Tool Performance | General Purpose |
| Primary Workpiece Material | Super-alloys & Titanium |
| Primary Workpiece Material Code | S |
| Through Coolant | Normal Pressure |
| Insert Holding Method | Wedge |
| Hub Diameter (Decimal Inch) | 46.0000 |
| Cutting Direction | Right Hand |
| Maximum Cutting Diameter (Decimal Inch) | 50.00 mm |
| Minimum Cutting Diameter (Decimal Inch) | 38.00 mm |
