Indexable Copy Face Mills; Maximum Depth Of Cut: 2.50 mm; Compatible Insert Size Code: RNHU 1004..; Arbor Hole Diameter (mm): 22.00; Maximum Ramping Angle: 0 ™; Overall Height (mm): 40.00 mm; Series: A252-10; Number of Cutter Inserts: 7; Cutter Style: A2
Item #: 33950528
Brand: Ceratizit
Model #: 50689152
Product Specifications
| Maximum Depth Of Cut | 2.50 mm |
| Compatible Insert Size Code | RNHU 1004.. |
| Arbor Hole Diameter (mm) | 22.00 |
| Maximum Ramping Angle | 0 ? |
| Overall Height (mm) | 40.00 mm |
| Series | A252-10 |
| Number of Cutter Inserts | 7 |
| Cutter Style | A252 |
| Maximum Rpm | 12000.000 |
| Tool Application | Face Milling |
| Tool Performance | General Purpose |
| Primary Workpiece Material | Universal |
| Through Coolant | Normal Pressure |
| Insert Holding Method | Screw; Clamp |
| Hub Diameter (Decimal Inch) | 43.0000 |
| Cutting Direction | Right Hand |
| Maximum Cutting Diameter (Decimal Inch) | 52.00 mm |
| Minimum Cutting Diameter (Decimal Inch) | 42.00 mm |
