Brand: Ingersoll Cutting Tools / Part #: 2922436
Item #: 96743521
Brand: Ingersoll Cutting Tools
Model #: 2922436
Product Specifications
| Minimum Cutting Diameter (Decimal Inch) | 2.0000 |
| Minimum Cutting Diameter (Inch) | 2 |
| Maximum Cutting Diameter (Decimal Inch) | 2.0000 |
| Maximum Cutting Diameter (Inch) | 2 |
| Maximum Depth of Cut (mm) | 105.66 |
| Maximum Depth of Cut (Decimal Inch) | 4.1600 |
| Cutter Style | 22J3G |
| Shank Type | Weldon Flat |
| Shank Diameter (Decimal Inch) | 2.0000 |
| Shank Diameter (Inch) | 2 |
| Maximum Ramping Angle | 4 ? |
| Insert Holding Method | Screw |
| Overall Length (mm) | 209.5500 |
| Overall Length (Decimal Inch) | 8.2500 |
| Tool Material | Steel |
| Series | 22J3G |
| Flute Type | Spiral |
| Lead Angle | 90 |
| Shank Length (Inch) | 3-1/4 |
| Shank Length (Decimal Inch) | 3.2500 |
| Head Length (Inch) | 5 |
| Head Length (Decimal Inch) | 5.0000 |
| Tool Application | Facing; Shouldering |
| Tool Performance | General Purpose |
| Primary Workpiece Material | Universal |
| End Mill Type | Rougher/Finisher |
| Rake | Positive |
| Complete Insert Compatibility | AOxT1705..; BOCT1705..; ZOxT1705.. |
| Insert Compatibility | AOxT1705..; BOCT1705..; ZOxT1705.. |
| Hand of Holder | Right Hand |
| Multi-Use Tool | Yes |
| Manufacturers Catalog Number | 22J3G-2005082R01 |
| Usable Length (mm) | 124.460 |
| Number Of Flutes | 4 |
| Usable Length (Decimal Inch) | 4.9000 |
| Number Of Cutter Inserts | 28 |
| Coolant Through | Yes |
