Kennametal - 5" Groove Width, 19mm Max Depth of Cut, Right Hand Cut, A4M-C Indexable Grooving Blade - 5mm Insert Width, 5 Seat Size, A4G0500M05P Insert Style, Series A4
Item #: 31607021
Brand: Kennametal
Model #: 6401819
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Cutting Direction | Right Hand |
| Minimum Groove Width (mm) | 5.00 |
| Maximum Insert Width (mm) | 5.00 |
| Minimum Insert Width (mm) | 5.00 |
| Maximum Depth of Cut (mm) | 19.00 |
| Blade Style | A4M-C |
| Series | A4 |
| Blade Height (mm) | 34.29 |
| Blade Width (mm) | 11.65 |
| Maximum Groove Width (mm) | 5.00 |
| Overall Length (mm) | 59.75 |
| Blade Overall Length (mm) | 5.00 |
| Manufacturers Catalog Number | A4M50R0519MC |
| Insert Style | A4G0500M05P |
| Insert Seat Size | 5 |
| Cartridge Size | 50 |
