Bilz - HSK63A Taper Shank 22mm Pilot Diam Shell Mill Holder - 50mm Flange to Nose End Projection, 48mm Nose Diam, M10 Lock Screw, Through-Spindle Coolant
Item #: 31246135
Brand: Bilz
Model #: 66661323M
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Shank Type | Taper Shank |
| Taper Size | HSK63A |
| Pilot Diameter (mm) | 22.00 |
| Projection Flange to Nose End (mm) | 50.00 |
| Through Coolant | Yes |
| Nose Diameter (mm) | 48.00 |
| Overall Length (Decimal Inch) | 4.1760 |
| Balanced to (RPM) | 8000 |
| TIR (mm) | 0.005 |
| Coolant Type | Through-Spindle |
| Lock Screw Thread Size | M10 |
