Bilz - HSK63A Taper Shank 27mm Pilot Diam Shell Mill Holder - 60mm Flange to Nose End Projection, 58mm Nose Diam, M12 Lock Screw, Through-Spindle Coolant
Item #: 31245608
Brand: Bilz
Model #: 66661325M
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Shank Type | Taper Shank |
| Taper Size | HSK63A |
| Pilot Diameter (mm) | 27.00 |
| Projection Flange to Nose End (mm) | 60.00 |
| Through Coolant | Yes |
| Nose Diameter (mm) | 58.00 |
| Overall Length (Decimal Inch) | 4.6490 |
| Balanced to (RPM) | 8000 |
| TIR (mm) | 0.005 |
| Coolant Type | Through-Spindle |
| Lock Screw Thread Size | M12 |
