Powers Fasteners - 3/4" Diam, 1/4" Drill, 3" OAL, 2-1/4" Min Embedment Sleeve Concrete Anchor - 304 Stainless Steel, Flat Head, Combination Slotted/Phillips Drive, 3" Thread Length - Benchmark Tooling

Powers Fasteners - 3/4" Diam, 1/4" Drill, 3" OAL, 2-1/4" Min Embedment Sleeve Concrete Anchor - 304 Stainless Steel, Flat Head, Combination Slotted/Phillips Drive, 3" Thread Length


Item #: 31188964
Brand: Powers Fasteners
Model #: 06172S-PWR
Exact Tooling IR#: 04

Features and Benefits

Sleeve concrete anchors are used in brick, concrete and grout-filled or hollow concrete block. They have an internal expander that pulls up and expands the anchor s sleeve when the anchor s nut is tightened. This increases holding power.
Stainless steel is a strong, corrosion-resistant alloy with excellent resistance to heat. It is used in high-stress, outdoor and corrosive applications.
Product Specifications
Type Sleeve
Diameter (Inch) 3/4
Drill Size (Inch) 1/4
Overall Length (Inch) 3
Minimum Embedment (Inch) 5/8
Material Stainless Steel
Material Grade 304
Head Type Flat
Thread Size #10-24
Drive Type Combination Slotted/Phillips
Thread Length (Inch) 3
For Use With Normal Weight Concrete; Structural Lightweight Concrete; Grouted Concrete Masonry; Hollow Concrete Masonry
System of Measurement Inch
