Iscar - RH SVPC 0° Neutral Rake Indexable Turning Toolholder
Item #: 30710255
Brand: Iscar
Model #: 3603098
Product Specifications
| Hand of Holder | Right Hand |
| Toolholder Style | SVPC |
| Rake | Neutral |
| Rake Angle | 0 |
| Series | Isoturn |
| Lead Angle | 117.5 |
| Shank Width (mm) | 12.00 |
| Shank Width (Decimal Inch) | 0.4724 |
| Shank Height (mm) | 12.00 |
| Shank Height (Decimal Inch) | 0.4724 |
| Overall Length (mm) | 125.00 |
| Overall Length (Decimal Inch) | 4.9213 |
| Insert Compatibility | VC..1103 |
| Multi-Use Tool | No |
| Insert Holding Method | Screw |
| Back of Bar to Cutting Edge (mm) | 12.20 |
| Back of Bar to Cutting Edge (Decimal Inch) | 0.4803 |
| Head Length (mm) | 22.00 |
| Head Length (Decimal Inch) | 0.8661 |
