Iscar - SVJC, Left Hand Cut, 93° Lead Angle, 10mm Shank Height x 10mm Shank Width, Neutral Rake Indexable Turning Toolholder - 125mm OAL, VC..1103 Insert Compatibility, Series Isoturn
Item #: 30710024
Brand: Iscar
Model #: 3603091
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Hand of Holder | Left Hand |
| Toolholder Style | SVJC |
| Rake | Neutral |
| Rake Angle | 0 |
| Series | Isoturn |
| Lead Angle | 93 |
| Shank Width (mm) | 10.00 |
| Shank Width (Decimal Inch) | 0.3937 |
| Shank Height (mm) | 10.00 |
| Shank Height (Decimal Inch) | 0.3937 |
| Overall Length (mm) | 125.00 |
| Overall Length (Decimal Inch) | 4.9213 |
| Insert Compatibility | VC..1103 |
| Multi-Use Tool | No |
| Insert Holding Method | Screw |
| Back of Bar to Cutting Edge (mm) | 10.20 |
| Back of Bar to Cutting Edge (Decimal Inch) | 0.4016 |
| Head Length (mm) | 22.00 |
| Head Length (Decimal Inch) | 0.8661 |
