Iscar - FSHD, External, Right Hand, 25.5mm Max Depth of Cut, 8mm Max Groove Width, Indexable Grooving Tool Holder - FSPA 80-40.. Insert Compatibility, 25mm Shank Height, 25mm Shank Width, 170mm OAL
Item #: 30706113
Brand: Iscar
Model #: 2801753
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Internal or External | External |
| Toolholder Type | NonFace Grooving |
| Hand of Holder | Right Hand |
| Maximum Depth of Cut (Decimal Inch) | 1.0039 |
| Maximum Depth of Cut (mm) | 25.50 |
| Maximum Groove Width (mm) | 8.00 |
| Maximum Groove Width (Decimal Inch) | 0.3150 |
| Overall Length (mm) | 170.00 |
| Overall Length (Decimal Inch) | 6.6929 |
| Toolholder Style | FSHD |
| Insert Compatibility | FSPA 80-40.. |
| Shank Height (mm) | 25.00 |
| Shank Height (Decimal Inch) | 0.9843 |
| Shank Width/Diameter (mm) | 25.00 |
| Shank Width/Diameter (Decimal Inch) | 0.9843 |
| Series | Fix-Grip |
| Through Coolant | Non Coolant Through |
| Multi-Use Tool | Yes |
| Multi-Use Application | Profiling; Turning |
| Insert Holding Method | Clamp |
| Back of Bar to Cutting Edge (mm) | 22.30 |
| Back of Bar to Cutting Edge (Decimal Inch) | 0.8780 |
| Head Length (mm) | 51.50 |
| Head Length (Decimal Inch) | 2.0276 |
| Shank Length (mm) | 118.50 |
| Shank Length (Decimal Inch) | 4.6654 |
| Complete Insert Compatibility | FSPA 80-40; FSPA 80-40-D; FSPA 80-40YZ; FSPA 80-40YZ-D |
