Milling Insert: TXL 225402 CWX500, CWX500, Solid Carbide N/A Finish,
Item #: 28731818
Brand: Ceratizit
Model #: 50382254
Product Specifications
| Insert Style | TX-L |
| Insert Size Code | 2254 |
| Insert Material | Solid Carbide |
| Manufacturer Grade | CWX500 |
| Inscribed Circle (Decimal Inch) | 0.5118 |
| Corner Radius (Decimal Inch) | 0.0059 |
| Insert Hand | Left Hand |
| Series | TX-L |
| Coating Process | Uncoated |
| Hole Diameter (Decimal Inch) | 0.2165 |
| Maximum Depth of Cut (Decimal Inch) | 0.2559 |
| Number Of Cutting Edges | 3 |
| Insert Shape | Triangle |
| Rake | Positive |
| Primary Workpiece Material | Non-Ferrous Metal; Stainless Steel; Cast Iron; Steel |
| Primary Workpiece Material Code | P; K; M; N |
| Secondary Workpiece Material | Super-Alloys & Titanium |
| Secondary Workpiece Material Code | S; N |
| Iso Code | TXL 225402 CWX500 |
| Chip Breaker | None |
| Coating/Finish | Uncoated |
| Thickness (Decimal Inch - 4 Decimals) | 0.2125 |
