Milling Insert: XDKT 11T316ER-F40 CTCM245, CTCM245, Solid Carbide N/A Finish,
Item #: 26222497
Brand: Ceratizit
Model #: 5111391601
Product Specifications
| Insert Style | XDKT |
| Insert Size Code | 11T3 |
| Insert Material | Solid Carbide |
| Manufacturer Grade | CTCM245 |
| Inscribed Circle (Decimal Inch) | 0.2677 |
| Corner Radius (Decimal Inch) | 0.0630 |
| Insert Hand | Right Hand |
| Relief Angle | 15.00 |
| Series | XDKT |
| Coating Process | CVD |
| Hole Diameter (Decimal Inch) | 0.1102 |
| Maximum Depth of Cut (Decimal Inch) | 0.2835 |
| Number Of Cutting Edges | 2 |
| Cutting Edge Effective Length (Decimal Inch) | 0.4173 |
| Insert Shape | Parallelogram |
| Rake | Positive |
| Primary Workpiece Material | Stainless Steel; Steel |
| Primary Workpiece Material Code | P; M |
| Secondary Workpiece Material | Super-Alloys & Titanium |
| Secondary Workpiece Material Code | S |
| Ansi Code | XDKT 11T316ER-F40 CTCM245 |
| Iso Code | XDKT 11T316ER-F40 CTCM245 |
| Chip Breaker | F40 |
| Coating/Finish | Coated |
| Thickness (Decimal Inch - 4 Decimals) | 0.1496 |
