Scientific Cutting Tools - 0.5000-20" Port, 0.675" Spotface Diam, 5/16" Tube Outside Diam, Reamer Pilot, Carbide Tipped Porting Tool
Item #: 54274022
Brand: Scientific Cutting Tools
Model #: MS21921-5A
Features and Benefits
Carbide-tipped cuts faster than high speed steel. It is commonly used on ferrous and nonferrous materials including cast iron, steel and steel alloys.
| Product Specifications | |
|---|---|
| Port Standard Designation | MS 21921 |
| Pilot Type | Reamer |
| Port Thread Size (Decimal Inch) | 0.5000-20 |
| Tool Material | Carbide-Tipped |
| Tube Dash Number | 5.000 |
| Tube Outside Diameter Compatibility (Decimal Inch) | 0.312 |
| Minimum Pilot Diameter (Decimal Inch) | 0.3680 |
| Maximum Pilot Diameter (Decimal Inch) | 0.6750 |
| Spotface Diameter (Decimal Inch) | 0.6750 |
| Pilot Length (Decimal Inch) | 0.2380 |
| Identification Groove | No |
| Workpiece Compatibility | Tubes |
| Finish/Coating | AlTiN+ |
| Head Length (Decimal Inch) | 1.5000 |
| Overall Length (Decimal Inch) | 3.2500 |
| Shank Diameter (Decimal Inch) | 0.5000 |
| Shank Length (Decimal Inch) | 1.7500 |
| Thread Type | UNJF |
| Flute Type | Straight |
| Number of Flutes | 3 |
