Seco - Arbor Connection, 10mm Cutting Width, 19.67mm Depth of Cut, 80mm Cutter Diam, 27" Hole Diam, 8 Tooth Indexable Slotting Cutter
Item #: 96584404
Brand: Seco
Model #: 03278720
| Product Specifications | |
|---|---|
| Connection Type | Arbor |
| Cutting Width (mm) | 10.00 |
| Cutting Width (Decimal Inch) | 0.3937 |
| Maximum Depth of Cut (mm) | 19.67 |
| Cutter Diameter (mm) | 80.00 |
| Hole Diameter (mm) | 27.00 |
| Number of Teeth | 8 |
| Toolholder Style | R335.29 |
| Series | R335.29 |
| Insert Style | RP..10 |
| Staggered Tooth | Yes |
| Number of Cutter Inserts | 8 |
| Cutting Direction | Right Hand |
| Insert Holding Method | Screw |
| Maximum RPM | 12000 |
| Keyway Width (mm) | 12.40 |
| Rake | Positive |
| Lead Angle | 90 |
