Mitutoyo - Mechanical Micrometer Heads Minimum Measurement (mm): 0.00 Maximum Measurement (mm): 13.00
Item #: 06236038
Brand: Mitutoyo
Model #: 148-503
Product Specifications
Mechanical Micrometer Heads; Minimum Measurement (mm): 0.00 ; Maximum Measurement (mm): 13.00 ; Thimble Diameter (mm): 13.00 ; Digital Counter: No ; Spindle Diameter (mm): 5.00 ; Spindle Length (mm): 13.00
| Minimum Measurement (mm) | 0.00 |
| Maximum Measurement (mm) | 13.00 |
| Thimble Diameter (mm) | 13.00 |
| Digital Counter | No |
| Spindle Diameter (mm) | 5.00 |
| Spindle Length (mm) | 13.00 |
| Overall Length (mm) | 75 (Closed) |
| Graduation (mm) | 0.0100 |
| Stem Diameter (mm) | 9.50 |
| Spindle Type | Flat |
| Rotating Spindle | Yes |
| Accuracy (micro m) | 2.00 |
| Thimble Type | Zero-Adjustable |
| Stem Length (mm) | 9.50 |
| Reverse Reading | No |
| Clamp Nut Supplied | No |
| Measuring Face Material | Steel |
| Finish/Coating | Chrome Plated |
