Supermill - Square End Mills Mill Diameter (Inch): 1 Mill Diameter (Decimal Inch): 1.0000
Item #: 30785828
Brand: Supermill
Model #: AL3F1.0-DLC
Features and Benefits
Solid carbide provides better rigidity than high speed steel. It is extremely heat resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
Diamond-like carbon (DLC) is an extremely hard and durable coating that is similar to diamond. It is commonly used on stainless steel, ceramics, plastics and aluminum alloys.
Product Specifications
Square End Mills; Mill Diameter (Inch): 1 ; Mill Diameter (Decimal Inch): 1.0000 ; Number of Flutes: 3 ; Length of Cut (Inch): 1-1/2 ; Length of Cut (Decimal Inch): 1.5000 ; Material: Solid Carbide
| Mill Diameter (Inch) | 1 |
| Mill Diameter (Decimal Inch) | 1.0000 |
| Number of Flutes | 3 |
| Length of Cut (Inch) | 1-1/2 |
| Length of Cut (Decimal Inch) | 1.5000 |
| Material | Solid Carbide |
| Finish/Coating | Diamond-Like Carbon (DLC) |
| Shank Diameter (Inch) | 1 |
| Shank Diameter (Decimal Inch) | 1 |
| Single or Double End | Single |
| Overall Length (Inch) | 4 |
| Overall Length (Decimal Inch) | 4 |
| Flute Direction | Right Hand |
| Cutting Direction | Right Hand |
| Helix Angle | 45 |
| Variable Helix | No |
| Variable Index | Yes |
| Material Grade | Micrograin |
| Chipbreaker | No |
| Series/List | AL3F |
