Shuster - UCFB206-20, 1-1/4" ID, 3-1/4" OAL x 136.5mm OAH x 1-5/8" Wide, 3-Bolt Flange Mounted Bearing
Item #: 18648659
Brand: Shuster
Model #: 06581996
Product Specifications
| Type | 3-Bolt Flange Mounted Bearing |
| Inside Diameter (Decimal Inch) | 1.2500 |
| Inside Diameter (Inch) | 1-1/4 |
| Width (Inch) | 1-5/8 |
| Width (mm) | 40.90 |
| Overall Length (Inch) | 3-1/4 |
| Overall Length (mm) | 82.6000 |
| Overall Height (Decimal Inch) | 4.5630 |
| Overall Height (mm) | 136.50000 |
| Distance Between Mounting Hole Centers | 47.6000 |
| Distance Between Mounting Hole Centers | 1.875 |
| Material | Cast Iron Housing with Steel Bearing |
| Lock Type | Set Screw |
