Shuster - SUCSPA207-23, 1-7/16" ID, 4-1/4" OAL x 3-3/4" OAH, Tap Base Pillow Block
Item #: 18648634
Brand: Shuster
Model #: 07469781
Product Specifications
| Type | Tap Base Pillow Block |
| Inside Diameter (Decimal Inch) | 1.4375 |
| Inside Diameter (Inch) | 1-7/16 |
| Width (Decimal Inch) | 1.8900 |
| Width (mm) | 48.00 |
| Overall Length (Inch) | 4-1/4 |
| Overall Length (mm) | 108.0000 |
| Overall Height (Inch) | 3-3/4 |
| Overall Height (Decimal Inch) | 3.7500 |
| Overall Height (mm) | 95.00000 |
| Distance Between Mounting Hole Centers | 82.6000 |
| Distance Between Mounting Hole Centers | 3.250 |
| Material | Stanless Housing With Stainless Steel Bearing |
| Distance Between Base And Center | 47.6000 |
| Distance Between Base And Center | 1.8750 |
| Lock Type | Set Screw |
