Shuster - UCT207-22, 1-3/8" ID, 102mm OAL x 129mm OAH42.9mm Wide, Ball Bearing Take-Up Unit
Item #: 18648451
Brand: Shuster
Model #: 07561649
Product Specifications
| Type | Ball Bearing Take-Up Unit |
| Inside Diameter (Decimal Inch) | 1.3750 |
| Inside Diameter (Inch) | 1-3/8 |
| Width (Decimal Inch) | 1.6880 |
| Width (mm) | 42.90 |
| Overall Length (mm) | 102.0000 |
| Overall Length (Decimal Inch) | 4.01500 |
| Overall Height (Decimal Inch) | 5.0780 |
| Overall Height (mm) | 129.00000 |
| Material | Cast Iron Housing with Steel Bearing |
| Distance Between Base And Center | 3.0630 |
| Distance Between Base And Center | 78.0000 |
| Lock Type | Set Screw |
