Shuster - SUCSFL207-22, 1-3/8" ID, 90mm OAL x 161mm OAH x 1-3/4" Wide, 2-Bolt Flange Bearing
Item #: 18647636
Brand: Shuster
Model #: 08102158
Product Specifications
| Type | 2-Bolt Flange Bearing |
| Inside Diameter (Decimal Inch) | 1.3750 |
| Inside Diameter (Inch) | 1-3/8 |
| Width (Inch) | 1-3/4 |
| Width (mm) | 44.40 |
| Overall Length (mm) | 90.0000 |
| Overall Length (Decimal Inch) | 3.54700 |
| Overall Height (Decimal Inch) | 6.3430 |
| Overall Height (mm) | 161.00000 |
| Distance Between Mounting Hole Centers | 130.0000 |
| Distance Between Mounting Hole Centers | 5.125 |
| Material | Stanless Housing With Stainless Steel Bearing |
| Distance Between Base And Center | 19.0000 |
| Distance Between Base And Center | 0.7500 |
| Lock Type | Set Screw |
