Shuster - SUCSFL209-27, 1-11/16" ID, 106.5mm OAL x 188mm OAH52.2mm Wide, 2-Bolt Flange Bearing
Item #: 18647370
Brand: Shuster
Model #: 07486488
Product Specifications
| Type | 2-Bolt Flange Bearing |
| Inside Diameter (Decimal Inch) | 1.6875 |
| Inside Diameter (Inch) | 1-11/16 |
| Width (Decimal Inch) | 2.0150 |
| Width (mm) | 52.20 |
| Overall Length (mm) | 106.5000 |
| Overall Length (Decimal Inch) | 4.18800 |
| Overall Height (Decimal Inch) | 7.4060 |
| Overall Height (mm) | 188.00000 |
| Distance Between Mounting Hole Centers | 148.0000 |
| Distance Between Mounting Hole Centers | 5.525 |
| Material | Stanless Housing With Stainless Steel Bearing |
| Distance Between Base And Center | 22.0000 |
| Distance Between Base And Center | 0.8750 |
| Lock Type | Set Screw |
