Shuster - UCF206-19, 1-3/16" ID, 4-1/4" OAL x 4-1/4" OAH, 4-Bolt Flange Bearing
Item #: 18624155
Brand: Shuster
Model #: 05607044
Product Specifications
Type | 4-Bolt Flange Bearing |
Inside Diameter (Decimal Inch) | 1.1875 |
Inside Diameter (Inch) | 1-3/16 |
Width (Decimal Inch) | 1.5930 |
Width (mm) | 40.20 |
Overall Length (Inch) | 4-1/4 |
Overall Length (mm) | 108.0000 |
Overall Height (Inch) | 4-1/4 |
Overall Height (Decimal Inch) | 4.2500 |
Overall Height (mm) | 108.00000 |
Distance Between Mounting Hole Centers | 83.0000 |
Distance Between Mounting Hole Centers | 3.250 |
Material | Cast Iron Housing with Steel Bearing |
Distance Between Base And Center | 18.0000 |
Distance Between Base And Center | 0.7080 |
Lock Type | Set Screw |
