Shuster - UCF207-23, 1-7/16" ID, 4-5/8" OAL x 4-5/8" OAH x 1-3/4" Wide, 4-Bolt Flange Bearing
Item #: 18624130
Brand: Shuster
Model #: 05607047
Product Specifications
Type | 4-Bolt Flange Bearing |
Inside Diameter (Decimal Inch) | 1.4375 |
Inside Diameter (Inch) | 1-7/16 |
Width (Inch) | 1-3/4 |
Width (mm) | 44.40 |
Overall Length (Inch) | 4-5/8 |
Overall Length (mm) | 117.0000 |
Overall Height (Inch) | 4-5/8 |
Overall Height (Decimal Inch) | 4.6250 |
Overall Height (mm) | 117.00000 |
Distance Between Mounting Hole Centers | 92.0000 |
Distance Between Mounting Hole Centers | 3.625 |
Material | Cast Iron Housing with Steel Bearing |
Distance Between Base And Center | 19.0000 |
Distance Between Base And Center | 0.7500 |
Lock Type | Set Screw |
