Kyocera BDMT 11T331ERJT PR1210 Grade PVD Carbide, Parallelogram, Positive Rake Angle, Right-Hand Milling Insert for Roughing in (K) Gray Cast Iron, (K) Nodular Cast Iron and (S) Titanium Alloy
Item #: 18247510
Brand: Kyocera
Model #: TKA00366
Product Specifications
| Insert Style | BDMT |
| Insert Size | 11T331 |
| Insert Material | Solid Carbide |
| Manufacturer Grade | PR1210 |
| Inscribed Circle (Decimal Inch) | 0.2638 |
| Thickness Range (Decimal Inch) | 0.1250 to 0.1500 |
| Corner Radius (Decimal Inch) | 0.1220 |
| Inscribed Circle Range (Decimal Inch) | 0.2500 to 0.3000 |
| Length Range (Decimal Inch) | 0.4000 to 0.4500 |
| Insert Hand | Right Hand |
| Coating Process | PVD |
| Hole Diameter (Decimal Inch) | 0.1102 |
| Maximum Depth of Cut (Decimal Inch) | 0.4331 |
| Rake | Positive |
| Ansi Code | BDMT11T331ERJTPR1210 |
| Iso Code | BDMT11T331ER-JT |
| Cutting Edge Style | Honed |
| Manufacturers Catalog Number | BDMT11T331ERJTPR1210 |
| Cutter Series Compatibility | MEC |
| Chip Breaker | JT |
| Cutting Direction | Right Hand |
| Shape | Parallelogram |
| Insert Holding Method | Screw |
| Coating/Finish | Megacoat |
| Width (Decimal Inch - 4 Decimals) | 0.2638 |
| Thickness (Decimal Inch - 4 Decimals) | 0.1496 |
| Length (Decimal Inch - 4 Decimals) | 0.4330 |
