Kyocera MFLN 45080R4T Inch Bore Diameter, Standard Pitch, 4 Flute, 45 Degree Face Mill with a 80.00mm Cutting Diameter for Shouldering, Facing, Chamfering Applications
Item #: 18241505
Brand: Kyocera
Model #: THN08464
Product Specifications
| Minimum Cutting Diameter (mm) | 80.00 |
| Maximum Cutting Diameter (mm) | 104.00 |
| Maximum Depth of Cut (mm) | 12.00 |
| Maximum Depth of Cut (Decimal Inch) | 0.4724 |
| Arbor Hole Diameter (Inch) | 1 |
| Lead Angle | 45 |
| Compatible Insert Size Code | LOGU221616ER-GM |
| Cutter Style | MFLN |
| Cutting Direction | Right Hand |
| Insert Holding Method | Screw |
| Series | MFLN |
| Overall Height (Mm - 5 Decimals) | 50.00 |
| Counterbore Diameter (Decimal Inch) | 0.7874 |
| Toolholder Material | Steel |
| Manufacturers Catalog Number | MFLN45080R4T |
| Number Of Cutter Inserts | 4 |
| Coolant Through | Yes |
| Number Of Flutes | 4 |
