Milling Insert: ROMX10T3M08-F67 WSM45X, WSM45X, Solid Carbide N/A Finish,
Item #: 16279507
Brand: Walter
Model #: 8127339
Product Specifications
| Insert Style | ROMX |
| Insert Size Code | 10 |
| Insert Material | Solid Carbide |
| Manufacturer Grade | WSM45X |
| Inscribed Circle (Decimal Inch) | 0.3940 |
| Thickness Range (Decimal Inch) | 0.1500 to 0.1750 |
| Corner Radius (Decimal Inch) | 0.1970 |
| Inscribed Circle Range (Decimal Inch) | 0.3500 to 0.4000 |
| Insert Hand | Neutral |
| Relief Angle | 11.00 |
| Series | ROMX |
| Coating Process | CVD |
| Hole Diameter (Decimal Inch) | 0.1540 |
| Number Of Cutting Edges | 8 |
| Cutting Edge Effective Length (mm) | 10.00 |
| Insert Shape | Round |
| Primary Workpiece Material | Super-Alloys & Titanium; Stainless Steel; Steel |
| Primary Workpiece Material Code | S; M |
| Iso Code | ROMX10T3M08-F67 WSM45X |
| Chip Breaker | F67 |
| Coating/Finish | Coated |
| Thickness (Decimal Inch - 4 Decimals) | 0.1560 |
