Square End Mill: 0.5512'' Dia, 1.1811'' LOC, 3 Flutes, Solid Carbide Single End, Uncoated, 45 ° Helix, Centercutting, RH Cut, RH Flute
Item #: 15268832
Brand: Micro 100
Model #: ARMM-140-3
Product Specifications
| Mill Diameter (Decimal Inch) | 0.5512 |
| Mill Diameter (mm) | 14.00 |
| Number Of Flutes | 3 |
| Length of Cut (mm) | 30.00 |
| End Mill Material | Solid Carbide |
| End Type | Single |
| Centercutting | Yes |
| Cutting Direction | Right Hand |
| Finish/Coating | Bright/Uncoated |
| Shank Diameter (mm) | 14.00 |
| Helix Angle | 45 |
| Variable Helix | No |
| Variable Index | No |
| Extended Reach | No |
| Overall Length (mm) | 83.00 |
| Length Of Cut Range (Decimal Inch) | 1.0000 - 1.2500 |
| Length of Cut (Decimal Inch) | 1.1811 |
| Shank Diameter (Decimal Inch) | 0.5512 |
| Flute Direction | Right Hand |
| Helix Style | Medium |
