Indexable Slotting Cutter: 4 mm Cutting Width, 100 mm Cutter Dia, Arbor Hole Connection, 25 mm Depth of Cut, 32 mm Hole, Neutral Screw, Uses 10 TX Inserts, 5 Teeth, Staggered, Positive, Steel, Black Oxide Finish
Item #: 15229479
Brand: Ceratizit
Model #: 50730104
Product Specifications
| Connection Type | Arbor Hole |
| Cutting Width (mm) | 4.00 |
| Maximum Depth of Cut (mm) | 25.00 |
| Hole Diameter (Mm) ( - 0 Decimals) | 32.00 |
| Cutter Diameter (mm) | 100.00 |
| Cutting Direction | Neutral |
| Insert Holding Method | Screw |
| Number Of Cutter Inserts | 10 |
| Compatible Insert Style | TX |
| Compatible Insert Size Code | TX. 162302 |
| Tooth Type | Staggered |
| Rake | Positive |
| Tool Material | Steel |
| Series | TX-STF-Z5 |
| Toolholder Style | TX.STF |
| Hub Diameter (mm) | 46.00 |
| Tool Application | Slotting |
| Primary Workpiece Material | Universal |
| Number Of Teeth | 5 |
| Coolant Through | No |
| Coating/Finish | Black Oxide |
