Milling Insert: LNMU0303ZER-MS AH3225, AH3225, Solid Carbide N/A Finish,
Item #: 14927362
Brand: Tungaloy
Model #: 6782086
Product Specifications
| Insert Style | LNMU |
| Insert Size Code | 0303 |
| Insert Material | Solid Carbide |
| Manufacturer Grade | AH3225 |
| Inscribed Circle (Decimal Inch) | 0.2360 |
| Corner Radius (Decimal Inch) | 0.0472 |
| Insert Hand | Right Hand |
| Relief Angle | 0.00 |
| Series | LNMU |
| Coating Process | PVD |
| Maximum Depth of Cut (Decimal Inch) | 0.0390 |
| Number Of Cutting Edges | 4 |
| Cutting Edge Effective Length (Decimal Inch) | 0.1260 |
| Insert Shape | Rectangle |
| Rake | Negative |
| Primary Workpiece Material | Stainless Steel; Steel |
| Primary Workpiece Material Code | P; M |
| Ansi Code | LNMU0303ZER-MS AH3225 |
| Iso Code | LNMU0303ZER-MS AH3225 |
| Chip Breaker | MS |
| Coating/Finish | Coated |
| Included Angle Degree | 90 |
| Thickness (Decimal Inch - 4 Decimals) | 0.1690 |
