Square End Mill: 3/4'' Dia, 1'' LOC, 3/4'' Shank Dia, 5'' OAL, 2 Flutes, Solid Carbide Single End, Uncoated, Upcut Flute, 45 ° Helix, Centercutting, RH Cut, RH Flute, Series 2012
Item #: 14562524
Brand: GWS
Model #: 314082
Product Specifications
| Mill Diameter (Inch) | 3/4 |
| Mill Diameter (Decimal Inch) | 0.7500 |
| Number Of Flutes | 2 |
| Length of Cut (Inch) | 1 |
| End Mill Material | Solid Carbide |
| End Type | Single |
| Centercutting | Yes |
| Cutting Direction | Right Hand |
| Shank Diameter (Inch) | 3/4 |
| Finish/Coating | Bright/Uncoated |
| Overall Length (Inch) | 5 |
| Helix Angle | 45 |
| Variable Helix | No |
| Variable Index | No |
| Extended Reach | Yes |
| Length of Cut (Decimal Inch) | 1.0000 |
| Material Grade | Submicron |
| Shank Diameter (Decimal Inch) | 0.7500 |
| Overall Length (Decimal Inch) | 5.0000 |
| Flute Direction | Right Hand |
| Flute Type | Upcut |
| Reach Length (Inch) | 2-1/2 |
| Series | 2012 |
