Indexable High-Feed Face Mills; Minimum Cutting Diameter: 1.4055 in; Maximum Cutting Diameter: 2.0000 in; Maximum Depth Of Cut: 0.0590 in; Arbor Hole Diameter (mm): 0.75; Compatible Insert Size Code: 0904; Maximum Ramping Angle: 1.4; Series: TXSW; Cutter
Item #: 14526479
Brand: Tungaloy
Model #: 6797113
Product Specifications
| Minimum Cutting Diameter | 1.4055 in |
| Maximum Cutting Diameter | 2.0000 in |
| Maximum Depth Of Cut | 0.0590 in |
| Arbor Hole Diameter (mm) | 0.75 |
| Compatible Insert Size Code | 0904 |
| Maximum Ramping Angle | 1.4 |
| Series | TXSW |
| Cutter Style | TXSW |
| Number of Cutter Inserts | 5 |
| Through Coolant | None |
| Keyway Width | 0.3150 |
| Overall Height | 1.9690 in |
| Tool Application | Face Milling |
| Tool Performance | General Purpose |
| Cutting Direction | Right Hand |
| Insert Holding Method | Screw |
| Number of Flutes | 5 |
