Indexable Insert Drills; Drill Style: TDSU; Maximum Drill Diameter (mm): 31.80; Maximum Drill Depth (mm): 96.10; Shank Type: Flatted; Shank Diameter (Inch): 32; Shank Diameter (mm): 32.00; Number of Drill Inserts: 2; Cutting Direction: Right Hand; Tool Ma
Item #: 13457015
Brand: Tungaloy
Model #: 6725980
Product Specifications
| Drill Style | TDSU |
| Maximum Drill Diameter (mm) | 31.80 |
| Maximum Drill Depth (mm) | 96.10 |
| Shank Type | Flatted |
| Shank Diameter (Inch) | 32 |
| Shank Diameter (mm) | 32.00 |
| Number of Drill Inserts | 2 |
| Cutting Direction | Right Hand |
| Tool Material | Steel |
| Compatible Insert Style | WWMU |
| Compatible Insert Size Code | 08X408 |
| Drill Depth by Diameter Ratio | 3xD |
| Coolant Entry Style Code | 1-Axial Concentric Entry |
| Overall Length (mm) | 184.10 |
| Series | TDS |
| Shank Length (mm) | 59.00 |
| Tool Application | Drilling |
| Tool Performance | General Purpose |
| Coolant Through | Yes |
