Indexable Square-Shoulder Face Mill: A211250R1011A100200EF, 2-1/2'' Cut Dia, 1.0000″ Arbor Hole Dia, 0.3940″ Max Cutting Depth Uses 10, XD.T 11T3 Inserts, Through Coolant, Series A211-11
Item #: 11952496
Brand: Ceratizit
Model #: 5873925010
Product Specifications
| Minimum Cutting Diameter (Decimal Inch) | 2.5000 |
| Minimum Cutting Diameter (Inch) | 2-1/2 |
| Maximum Cutting Diameter (Inch) | 2-1/2 |
| Maximum Cutting Diameter (Decimal Inch) | 2.5000 |
| Maximum Depth of Cut (Decimal Inch) | 0.3940 |
| Arbor Hole Diameter (mm) | 1.00 |
| Arbor Hole Diameter (Inch) | 1 |
| Arbor Hole Diameter (Decimal Inch) | 1.0000 |
| Compatible Insert Size Code | XD.T 11T3 |
| Maximum Ramping Angle | 1.80 |
| Cutter Style | A211 |
| Cutting Direction | Right Hand |
| Insert Holding Method | Screw |
| Lead Angle | 90 |
| Rake | Positive (Axial) |
| Series | A211-11 |
| Maximum Body Diameter (Decimal Inch) | 2.5000 |
| Overall Height (Inch) | 2-1/4 |
| Overall Height (Decimal Inch) | 2.2500 |
| Hub Diameter (mm) | 2.25 |
| Hub Diameter (Decimal Inch) | 2.2500 |
| Hub Diameter (Inch) | 2-1/4 |
| Maximum RPM | 23300 |
| Tool Application | Facing; Helical Interpolation; Ramping; Shouldering; Slotting |
| Primary Workpiece Material | Universal |
| Toolholder Material | Steel |
| Coolant Through | Yes |
| Number Of Cutter Inserts | 10 |
| Number Of Flutes | 10 |
