Harvey Tool - Ball End Mills; Mill Diameter (Inch): 1/64 ; Mill Diameter (Decimal Inch): 0.0150 ; Number of Flutes: 2 ; Length of Cut (Decimal Inch): 0.0450 ; Material: Solid Carbide ; Overall Length (Inch): 1-1/2
Item #: 11950060
Brand: Harvey Tool
Model #: 950215
Product Specifications
Ball End Mills; Mill Diameter (Inch): 1/64 ; Mill Diameter (Decimal Inch): 0.0150 ; Number of Flutes: 2 ; Length of Cut (Decimal Inch): 0.0450 ; Material: Solid Carbide ; Overall Length (Inch): 1-1/2
| Mill Diameter (Inch) | 1/64 |
| Mill Diameter (Decimal Inch) | 0.0150 |
| Number of Flutes | 2 |
| Length of Cut (Decimal Inch) | 0.0450 |
| Material | Solid Carbide |
| Overall Length (Inch) | 1-1/2 |
| Overall Length (Decimal Inch) | 1.50000 |
| Shank Diameter (Inch) | 1/8 |
| Shank Diameter (Decimal Inch) | 0.1250 |
| Finish/Coating | Uncoated |
| Single or Double End | Single |
| Helix Angle | 30 |
| Variable Helix | No |
| Reach Length (Inch) | 3/16 |
| Reach Length (Decimal Inch) | 0.1870 |
| Series/List | Miniature End Mills - Ball - Long Reach, Standard Flute |
| Cutting Direction | Right Hand |
| Flute Direction | Right Hand |
