Indexable Insert Drills; Drill Style: KUBP; Drill Diameter (Decimal Inch): 0.5709; Drill Diameter (mm): 14.50; Maximum Drill Depth (mm): 60.00; Shank Type: Modular Connection; Shank Diameter (mm): 28.00; Drill Diameter Range (Decimal Inch): 0.0000 to 0.75
Item #: 11633237
Brand: Komet
Model #: 1087414595
Product Specifications
| Drill Style | KUBP |
| Drill Diameter (Decimal Inch) | 0.5709 |
| Drill Diameter (mm) | 14.50 |
| Maximum Drill Depth (mm) | 60.00 |
| Shank Type | Modular Connection |
| Shank Diameter (mm) | 28.00 |
| Drill Diameter Range (Decimal Inch) | 0.0000 to 0.7500 |
| Cutting Direction | Right Hand |
| Maximum Drill Depth Range (mm) | 50.00 to 75.00 |
| Tool Material | Steel |
| Compatible Insert Style | SOGX |
| Drill Depth by Diameter Ratio | 4xD |
| Series | 10874 |
| Flute Length (mm) | 60.00 |
| Body Length | 88.00 |
| Shank Length (mm) | 31.00 |
| Modular Connection Size | ABS 50 |
| Overall Length/Projection (mm) | 119.00 |
| Collar Diameter (mm) | 50.00 |
| Coolant Through | Yes |
