Indexable Square-Shoulder Face Mill: A211.100.R.06-15, 32.0000″ Arbor Hole Dia, Uses 6, XD.T 1505 Inserts, Through Coolant, Series A211-15
Item #: 10035566
Brand: Ceratizit
Model #: 50748100
Product Specifications
| Minimum Cutting Diameter (mm) | 100.00 |
| Maximum Cutting Diameter (mm) | 100.00 |
| Maximum Depth of Cut (mm) | 14.00 |
| Arbor Hole Diameter (mm) | 32.00 |
| Arbor Hole Diameter (Inch) | 32 |
| Arbor Hole Diameter (Decimal Inch) | 32.0000 |
| Compatible Insert Size Code | XD.T 1505 |
| Maximum Ramping Angle | 1.00 |
| Cutter Style | A211 |
| Cutting Direction | Right Hand |
| Insert Holding Method | Screw |
| Lead Angle | 90 |
| Rake | Positive (Axial) |
| Series | A211-15 |
| Overall Height (Mm - 5 Decimals) | 78.00 |
| Hub Diameter (mm) | 50.00 |
| Hub Diameter (Decimal Inch) | 50.0000 |
| Hub Diameter (Inch) | 50 |
| Maximum RPM | 15680 |
| Tool Application | Facing; Helical Interpolation; Ramping; Shouldering; Slotting |
| Primary Workpiece Material | Universal |
| Toolholder Material | Steel |
| Coolant Through | Yes |
| Number Of Cutter Inserts | 6 |
| Number Of Flutes | 6 |
