Indexable Square-Shoulder Face Mill: A491200R0609A075175EF, 2'' Cut Dia, 0.7500″ Arbor Hole Dia, 0.2360″ Max Cutting Depth Uses 6, SNHU 09T3 Inserts, Through Coolant, Series A491-09
Item #: 09970443
Brand: Ceratizit
Model #: 5877520006
Product Specifications
| Minimum Cutting Diameter (Decimal Inch) | 2.0000 |
| Minimum Cutting Diameter (Inch) | 2 |
| Maximum Cutting Diameter (Inch) | 2 |
| Maximum Cutting Diameter (Decimal Inch) | 2.0000 |
| Maximum Depth of Cut (Decimal Inch) | 0.2360 |
| Arbor Hole Diameter (mm) | 0.75 |
| Arbor Hole Diameter (Inch) | 3/4 |
| Arbor Hole Diameter (Decimal Inch) | 0.7500 |
| Compatible Insert Size Code | SNHU 09T3 |
| Maximum Ramping Angle | 0.00 |
| Cutter Style | A491 |
| Cutting Direction | Right Hand |
| Insert Holding Method | Screw |
| Lead Angle | 90 |
| Rake | Negative |
| Series | A491-09 |
| Maximum Body Diameter (Decimal Inch) | 2.0000 |
| Overall Height (Inch) | 1-3/4 |
| Overall Height (Decimal Inch) | 1.7500 |
| Hub Diameter (Decimal Inch) | 1.7500 |
| Hub Diameter (Inch) | 1-3/4 |
| Maximum RPM | 9700 |
| Tool Application | Facing; Shouldering; Slotting |
| Primary Workpiece Material | Universal |
| Toolholder Material | Steel |
| Coolant Through | Yes |
| Number Of Cutter Inserts | 6 |
| Number Of Flutes | 6 |
