Kennametal - PSBN, Left Hand Cut, 15° Lead Angle, 40mm Shank Height x 40mm Shank Width, Negative Rake Indexable Turning Toolholder - 250mm OAL, SN..2507.. Insert Compatibility, Series Kenlever
Item #: 09835984
Brand: Kennametal
Model #: 1244675
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Hand of Holder | Left Hand |
| Toolholder Style | PSBN |
| Rake | Negative |
| Series | Kenlever |
| Lead Angle | 15 |
| Shank Width (mm) | 40.00 |
| Shank Width (Decimal Inch) | 1.5748 |
| Shank Height (mm) | 40.00 |
| Shank Height (Decimal Inch) | 1.5748 |
| Overall Length (mm) | 250.00 |
| Overall Length (Decimal Inch) | 9.8425 |
| Insert Compatibility | SN..2507.. |
| Multi-Use Tool | No |
| Insert Holding Method | Screw or Clamp |
| Back of Bar to Cutting Edge (mm) | 35.00 |
| Head Length (mm) | 47.00 |
| Head Length (Decimal Inch) | 1.8504 |
| Insert Inscribed Circle (Inch) | 1 |
| Insert Inscribed Circle (Decimal Inch) | 1.0000 |
| Toolholder Material | Steel |
